Home - Products - Muffle Furnace and Tube Furnace - High temperature creep and refractoriness under load RUL tester for refractory materials
It is used to test the load softening temperature, high temperature pressure creep and thermal expansion performance under various loads of various refractory products and amorphous materials.
Technical Parameters
t is used to test the load softening temperature, high temperature pressure creep and thermal expansion performance under various loads of various refractory products and amorphous materials.
Using silicon molybdenum bar as heating element
Loading mode: KS-MFT-HRY-03 lever loading mechanism,KS-MFT-HRY-04 direct pressure mechanism,
Corundum parts: imported material AL2O3 99.5%
Sample φ50×φ12.5×50 mm
Brand computer, Dual PID auto tuning automatic control, Windows operating system, dynamic real-time recording, display the deformation-temperature, temperature-time and creep rate-time curve, the test data using the ACCESS database, can query at any time using third party software.
Technical Parameters:
| ParameterModel | KS-MFT-HRY-03 | KS-MFT-HRY-04 | RUL-CIC 1701 RUL-CIC 1704RUL-CIC 1702 RUL-CIC 1705RUL-CIC 1703 RUL-CIC 1706 |
| Deformation range | 0~10mm | ||
| Service temperature | Lotus soft RUL 1700℃ creep CIC 1600℃ | ||
| Deformation measurement accuracy | 0.1% | ||
| Testing principle | Differential method | Differential method or non differential method | |
| Loading range | 0~0.5MPa | ||
| Test atmosphere | Standard type: natural air atmosphere;Q type: protective atmosphere | ||
| Sample quantity | 1 pc | 1~6 pcs | |
| Furnace body structure | Classic bell jar | Classic split | Energy saving open type |
