This equipment is suitable for all kinds of lithium-ion battery, nickel-metal hydride, nickel-cadmium and lead-acid battery external short-circuit test, simulated battery in the course of the accident caused by short circuit and make changes in the battery to observe.
Technical Parameters
Product Application:
This equipment is suitable for all kinds of lithium-ion battery, nickel-metal hydride, nickel-cadmium and lead-acid battery external short-circuit test, simulated battery in the course of the accident caused by short circuit and make changes in the battery to observe.
Technical Parameters:
| specification | KS-BTS-DL1000A |
| Operating current (A) | 1000 |
| Rated insulation voltage (V) | 1000 |
| System resistance | ≤100m ≤5m |
| Accessibility (optional) | Temperature, current, electric geese collection, fire extinguishing system, smoke holding system, smoke filtration system, safety explosion-proof system, video surveillance system |
| Operation method | Remote control |
| Explosion - proof box specifications | 600 * 600 * 600 800 * 800 * 800 1000 * 1000 * 1000 (can be customized) |
| Specimen size | Customized according to customer test samples |
| Test the firearm | Specific fixture, tailored to product characteristics and use |
| Temperature control system | RT ℃ '+ 150Y: Note: temperature and room temperature short circuit function, room temperature short circuit box only room temperature short circuit function |
| safety protection | Overvoltage, overload, over current, over temperature, leakage protection, smoke alarm, test abnormal alarm |
| Box | Vertical or horizontal (depending on test sample) |
| Control box | The control box is separate from the test chamber to ensure the safety of the test personnel |
| Fixture | Terminals or samples provided by the customer for sample customization |
| Data acquisition module | Remote isolation independent acquisition, multi-channel voltage, current, temperature acquisition channel, to ensure accurate data collection |
| Number of channels | 2 channels, 4 channels, 8 channels, a variety of acquisition systems (optional) |
| communication | Using R232,485 communication interface to ensure the stability of long-distance data acquisition and real-time, and has an explosion-proof function |
| Camera monitoring system | Detection area with high-definition camera monitoring system, remote control, and has an explosion-proof function |
| Voltage selection | 0-10V、0-100V、0-1000V |
| Temperature acquisition range | -150℃-1200℃ |
| Voltage resolution | 1mV |
| Current resolution | 0.1A |
| Temperature resolution | 0.l℃ |
| Maximum instantaneous current | 1500A |
| Voltage, temperature accuracy | ±1％FS |
| Current accuracy | 土1％FSR |
| Resistance material | all bronze |
| Response time | ≤5 u S |
| Action time | Pull-in / release time <30ms |
| Short circuit retention time | 0 ~ 999S, when the smell and the state can be adjusted according to the test requirements |
| Drive mode | Electric / pneumatic (depending on the test sample) |
